Tin Knocker HM Machinery 48” x 18 Ga. Power Slip Roll TTE 12/12

Tin Knocker HM Machinery 48” x 18 Ga. Power Slip Roll TTE 12/12 is a Tin Knocker product in the Slip Rolls collection.

Product Details

• Maximum Material Width: 48”
• Maximum Material Capacity: 18-Gauge Mild Steel
• Roller Diameter: 2.4"/60mm
• Minimum Bending Diameter: 3.5"/90mm
• Description
• The HM Machinery TTE Power Slip Roll has asymmetric rolls and adjustable roller speed, making pre-bending easy and accurate.
• The rolls are crowned for the straight rolling pinch. Both the lower roll and bending roll are easily adjusted by a worm-gear handle.
• The lower and rear roller come standard with fire groove for rolling wire profiles.
• The TTE comes as standard with a 0.75 KW brake motor, inverter, forward/backwards foot pedal fitted with an emergency stop.
• Specifications
• Wiring: Available in 1PH and 3PH
• Approx. Shipping Dimensions: 67” x 22” x 40”
• Approx. Shipping Weight: 620lbs.

Specifications

• Manufacturer: Tin Knocker
• SKU: TTE 1212
• Shipping Method: LTL Freight
• Weight: 620 lb
• Dimensions: 67 × 22 × 40 in
• Country of Origin: Denmark
• Warranty: 1 Year (Parts)
