Revolution Machine Tools 5HP 130 Ton H-Frame Hydraulic Press H-FAB H130

Revolution Machine Tools 5HP 130 Ton H-Frame Hydraulic Press H-FAB H130 is a Revolution Machine Tools product in the Hydraulic Presses collection.

Product Details

• Clear Front: 47”
• Clear Side: 16”
• Stroke: 16”
• Daylight: 35.4”
• Description
• RMT H-FAB H presses come in standard sizes and can be customized and produced according to customer’s purpose. These are workshop-type presses and can be manufactured up to 1100 Tons in automatic and manual as optional. They are used mostly in repair and maintenance workshops for small bending, punching, straightening, and extracting/removing.
• Features
• Chrome plated cylinder
• Steel welded frame
• Oil pressure gauge
• Pressure adjustment
• 2 speed hydraulics
• Large ram stroke
• Movable cylinder (left to right)
• V-block with working plate
• Common off the shelf components, typically of German or USA origin (Rex roth, Parker, Sneiders, and Seimens)
• Specifications
• Ton: 130
• Motor Power: 5 HP
• Down Speed: 14” I.P.M.
• Return Speed: 23” I.P.M.
• Foot Length: 39”
• Foot Width: 64”
• Machine Dims. (L x W x H): 39” x 75” x 97”
• Voltage: 3 Phase
• Weight: 2,756 lbs. 2956
• Options
• Pressure regulator
• Automatic control
• Hydraulic movable cylinder motion – by an additional hydraulic cylinder
• Die sets
• Stroke, open height and widths
• Included press
• Rolling bolsters
• Custom daylight, closed height, stoke, and tonnage to 330 ton
• Vertical, horizontal, or inclined frames

Specifications

• Manufacturer: Revolution Machine Tools
• SKU: H-FAB H130
• Shipping Method: Flatbed
• Weight: 2,956 lb
• Dimensions: 44 × 80 × 102 in
• Country of Origin: Turkey
• Warranty: 1 Year (Parts)
