Ercolina 220V Single Phase Manual Angle Roll Bender with 1½” Pipe Bending Capacity and Universal Tooling CE35

Ercolina 220V Single Phase Manual Angle Roll Bender with 1½” Pipe Bending Capacity and Universal Tooling CE35 is a Ercolina product in the Roll Benders collection.

Product Details

• Pipe Capacity (max): 1½” Sch. 40
• Angle Capacity (max): 1½” x 1½” x ¼”
• Roll Shaft Diameter: 40mm
• Operating Voltage: 220V Single Phase
• Description
• Ercolina’s CE35 angle roll models offer convenient single-phase power and manual center roll positioning. Vertical or horizontal operating position available.
• Ercolina’s affordable tube benders and fabricating machines are designed to reliably and accurately produce your bending applications. As a result, Ercolina machines will increase profit, as well as improve product quality and finish.
• Features
• 40mm roll shaft diameter
• Bending speeds 20% faster than competitive machines
• Universal tooling set included with each machine
• Forged roll shafts precision ground and fitted for maximum performance and minimal deflection
• Roll shafts supported with conical steel bearings on each side of A Frame
• Heavy duty structure and rigid components for high section modulus ratings
• Two bending speeds
• Reinforced engineered mainframe design proven to outperform competitive models
• Heavy duty gearbox drives lower roll shafts
• Threaded roll shafts with micrometric flange adjustment helps eliminate spacer usage
• Control tower with foot pedal operation of roll movement
• All capacities based on mild grade materials; heavy wall and high tensile materials reduce machine capacity
• Specifications
• Tube Capacity (max): 2” (0.156 wall)
• Center Roll Positioning: Manual
• Shaft Speed: 6 or 12 RPM
• Universal Tooling (included): 6⅝” O.D.
• Programming: Not available
• Distance between shafts: 11⅜″
• Dimensions (LxWxH): 27½” x 25½” x 59”
• Weight: 480 lbs
• Options
• Anti-twist correction system required for angle iron “Leg In” applications
• Small Radius Tooling (C4RR)
• Fabricator's measuring set (KARC)

Specifications

• Manufacturer: Ercolina
• SKU: CE35
• Shipping Method: LTL Freight
• Weight: 480 lb
• Dimensions: 48 × 48 × 65 in
• Country of Origin: Italy
