Ellis Manufacturing 110V Single Phase Dual Mitre Band Saw 1800

Ellis Manufacturing 110V Single Phase Dual Mitre Band Saw 1800 is a Ellis Manufacturing product in the Band Saws collection.

Product Details

• Round Capacity: 11” at 90°
• Flat Capacity: 14” at 90°
• Motor: 1 HP 110 Volt Single Phase
• Vise: Quick Adjusting Camlock
• Features
• Head of band saw moves left or right for angle cutting
• Built-in Protractor for fast and accurate selection of angles
• Stock remains in one position for all cuts
• Specifications
• Capacity (90° & 45°): 11” Round at 90° 10” Pipe at 90° 14” Flat at 90° 11” H x 10” W at 90° 9” Round at 45° 8” Pipe at 45° 9” Flat at 45° 11” H x 6” W at 45°
• 11” Round at 90°
• 10” Pipe at 90°
• 14” Flat at 90°
• 11” H x 10” W at 90°
• 9” Round at 45°
• 8” Pipe at 45°
• 9” Flat at 45°
• 11” H x 6” W at 45°
• Blade Speeds (3): 55-115-230 FPM
• Blade Size: 11’0” x 1”
• Feed Control: Hydraulic Adjusting
• Shut Off: Automatic
• Motor – Standard: 1 H.P. 110 Volt Single Phase
• Shipping Weight: 650 lbs.
• Machine Size: Table Height: 28” Length: 66” Width: 29-3/8” Height: 47”
• Table Height: 28”
• Length: 66”
• Width: 29-3/8”
• Height: 47”
• Sealed Oil Bath Worm Gear: Standard
• Removable Chip Tray: Standard
• Construction: Heavy Steel; Welded & Machined for Accuracy & Durability
• Available Accessories
• Air System
• 2 Roller Support Stand with Stock Gauge and Micro-Adjuster
• Single Stock Stand – 1 Roller
• Stock Stand – 5’ Long
• (12″ W or 20″ W ) 4-Rollers
• Pipe Clamp Attachment for Camlock Vise
• Screw Type Vise
• Pipe Clamp Attachment for Screw Vise
• Vertical Table (11” x 20”) with Blade Guard and Post
• Mobil Unit Kit – Dual Wheel (Must be factory installed!)

Specifications

• Manufacturer: Ellis Manufacturing
• SKU: Ellis1800 (110V)
• Shipping Method: LTL Freight
• Weight: 710 lb
• Dimensions: 80 × 33 × 55 in
• Country of Origin: United States of America
• Warranty: 1 Year (Parts)
