U.S. Industrial 2HP 220V Three Phase 18” x 7” Manual Toolroom Surface Grinder USG618A-S

U.S. Industrial 2HP 220V Three Phase 18” x 7” Manual Toolroom Surface Grinder USG618A-S is a U.S. Industrial Machinery product in the Grinding & Sanding collection.

Product Details

• Type of Operation: All Manual
• Table/Cross Travel Max: 18” x 7”
• Grinding Wheel Supplied: 7” x 1/2” – 1.25” hole
• Spindle RPM: 3360
• Description
• U.S. Industrial Machinery has you covered with all of the machinery to perform artistic metalworking jobs right down to the finish. Their surface grinder inventory includes four models that offer varying levels of grinding but all provide the finish you need. U.S. Industrial’s company prides itself on the high level of customer service they provide each customer. This includes our ongoing support for you with your products, including their warranty, troubleshooting support, and traveling field technicians.
• This is a light duty toolroom Surface Grinder with MANUAL reciprocation of table and cross feed. Down feed increment is also manually set by operator.
• Types of Surface Grinder Operation Each one of their surface grinders includes a two-axis readout. Operation type varies by model number, but you can find a machine that offers all manual operation, electric reciprocating and electric cross, or hydraulic reciprocating and electric cross. Each one is capable of 220- or 440-volt 3-phase electric power.
• Each one of their surface grinders includes a two-axis readout. Operation type varies by model number, but you can find a machine that offers all manual operation, electric reciprocating and electric cross, or hydraulic reciprocating and electric cross. Each one is capable of 220- or 440-volt 3-phase electric power.
• Standard Equipment
• Grinding Wheel
• Balancing Base and Arbor
• Table Dresser with Diamond Nib
• Manual One-Shot Lube
• Permanent Magnetic Chuck: 5.9” x 15.75”
• Wheel Flange
• Toolbox and Tools
• Coolant System
• Sino Two-Axis Digital Readout
• Specifications
• Two-Axis Readout Included: Yes
• Slideway Type: V Rail with Ball Track
• Machine Lube System: One-Shot Manual
• Function of Table Reciprocation: Manual-handwheel only
• Wheelhead Movement Up/Down: Handwheel-manual
• Wheelhead Dial Graduation: 0.0002”
• Perm mag chuck included: 5.9” x 15.75”
• Pole Spacing of Mag Chuck: 0.125”
• Cross Dial Graduation: 0.0005”
• Parallelism & Flatness Accuracy: <0.0008”
• Max. Distance Spindle Center To Table: 13”
• Dist Under Wheel to Chuck: 7-1/2”
• Wheel Balancing Arbor/Base: Yes – included
• Over Wheel Diamond Dresser: No – table dresser
• Worklight: Included
• Spindle HP: 2 HP
• Coolant Pump – Tank Size: 40 watt – 9 Gallons
• Voltage: 220V, 3 phase or 440V, 3 phase
• Full Load Amps @ 220 Volts: 4
• Gross Weight: 1,690 lbs.
• Dimensions (L x W x H): 45” x 40” x 70”
• Options
• Extra general purpose factory grinding wheel
• Extra wheel flange

Specifications

• Manufacturer: U.S. Industrial Machinery
• SKU: USG618A-S (220V)
• Shipping Method: Flatbed
• Weight: 1,790 lb
• Dimensions: 50 × 45 × 75 in
• Country of Origin: United States of America
• Warranty: 1 Year (Parts)
