Mittler Bros 6’ Sheet Metal Radius Brake Including 5 Radii’s 2800-7216RB

Mittler Bros 6’ Sheet Metal Radius Brake Including 5 Radii’s 2800-7216RB is a Mittler Bros product in the Sheet Metal Brakes collection.

Product Details

• Max Capacity: 11 Ga Aluminum, 16 Ga Mild Steel
• 1", 2", 2-1/2", 3", & 4" diameter tubes included
• Heavy duty plate construction
• Quick tooling change over
• Description
• This 6-foot sheet metal radius brake is the perfect solution for forming radius bends in mild steel and aluminum. Stress and cracking of material are minimized due to the unique design of the apron, which swings outside the radius and rolls across the material.
• Heavy duty plate construction, quick tooling change over, and convenient radius roll storage on the machine make this brake durable and easy to use. Especially useful in race car fabrication, as well as automotive and aircraft restoration work, this brake is an excellent addition to any sheet metal fabrication shop.
• Includes:
• 1", 2", 2-1/2", 3", & 4" diameter tubes included with 6’ machines
• Specifications
• Part: 2800-7216RB
• Length: 72"
• Brake Type: Radius Brake
• Max Capacity: 11 Ga (.090") Aluminum 16 Ga (.040") Mild Steel
• 11 Ga (.090") Aluminum
• 16 Ga (.040") Mild Steel
• Note:
• Tube sizes do not necessarily refer to finished part radius. Material type and thickness with affect the true finished radius.
• Tubes are used for radii 1" and larger.
• 2" Tube for 1" radius
• 2 1/2" Tube for 1 1/4" radius
• 3" Tube for 1 1/2" radius
• 4" Tube for 2" radius
• Radius Head for radii 1/2" or smaller.

Specifications

• Manufacturer: Mittler Bros
• SKU: 2800-7216RB
• Shipping Method: LTL Freight
• Weight: 840 lb
• Dimensions: 72 × 35 × 44 in
• Country of Origin: United States of America
• Warranty: 1 Year (Parts)
