Kalamazoo Machine Tool High Speed Circular Saw KMT CT 350 A-NC

Kalamazoo Machine Tool High Speed Circular Saw KMT CT 350 A-NC is a Kalamazoo Machine Tool product in the Cold Saws collection.

Product Details

• Blade Speeds: 3600 RPM
• Sawing Force: Infinitely Variably Adjustable
• Barfeed Accuracy +/- 0.005"
• Blade Size: 14"
• Description
• The CT 350 Series machines are high speed circular saws for aluminum extrusions and other non-ferrous materials. These machines feature swiveling capability for mitering and swiveling/tilting capability for compound mitering. The machine operates automatically with air over hydraulic system providing optimum sawing rates with minimum effort by the operator. The CT 350 A-NC is the easiest to use programmable saw on the market today. Length setup is digital, and 100 jobs may be stored for reuse, eliminating the need to set and reset various parameters. Do Not cut steel with this machine.
• Standard Equipment
• Heavy Duty Drive, TEFC Motor
• 24 Volt Controls
• Disconnect Switch
• Hydraulic oil
• Variable Vise Clamping Pressure
• Blade speed indicator
• Work height and depth controls
• Heavy Duty Drive
• Preset stops, 0,15,30,45 degrees
• Removable extruded special jaws
• Length stop assembly
• Carbide tipped Blade
• Built it spray mist coolant
• Operators Tools
• All Safety Guards
• Specifications
• Max Vise Opening: 8"
• Vises: Pneumatic, Infinitely Variable
• Clamping Pressure
• Weight Capacity: 880 lbs
• Blade Specifications: 14"
• Sawing Force: Infinitely Variable Adjustable
• Saw Frame Cycle Time: Raise, full stroke in 4 seconds
• Lower in 4 seconds
• Barfeed Cycle Time: Full strokes, 6 seconds
• Motors: Blade Drive 3 HP
• Work Height: 39.75"
• Automatic Feed Lengths: 1/8" to 20" (with 1 feed)
• 1/8" to infinite (with multiple feeds)
• Leftover Material Length: 8"
• Coolant Capacity: 5 Gallons
• Net Weight: 1600 lbs
• Machine Dimensions
• Across Front: 98"
• Front to Back: 52"
• Height: 77"
• Round: Square | Rectangle
• 90 Deg: 4.75" | 4.5" | 7.5" x 3.5"
• 45 Deg Right: 4.5" | 4" | 5.9" x 2.75"
• 45 Deg Left: 4.5" | 4" | 5.9" x 2.75"
• 60 Deg Right: 3" | 2.75" | 7" x 2.25"

Specifications

• Manufacturer: Kalamazoo Machine Tool
• SKU: CT 350 A-NC
• Shipping Method: LTL Freight
• Weight: 1,600 lb
