DoALL Semi-Automatic Band Saw DC-800SA

DoALL Semi-Automatic Band Saw DC-800SA is a DoALL Sawing Products product in the Band Saws collection.

Product Details

• Machine Capacity: 39.4" x 31.5"
• Production Level: High
• Band Speed: 85-279 FPM
• Cutting Capacity Round: 31.5"
• Description
• The DC-800SA Semi-Automatic Continental Series™ high production, horizontal band saws by DoALL are designed for cutting a wide range of metals on a production basis. While DoALL semi-automatic saws do not offer an auto-indexing, they do cut single pieces extremely efficiently. If you have operations that do not require indexing, high production or automatic cutting cycles, an affordable DoALL semi-automatic saws is the perfect choice. Once you have set your desired feed rate, blade speed and initial vise opening, a cut is complete, the band shuts off and the head returns to the upright open position and locks. Then the operator must manually reposition the material for another cut. Semi-automatic operation also increases blade life and cutting accuracy as the operator is not manually pressuring or overloading the saw blade during the cut.
• Standard Equipment
• Programmable Logic Controller (PLC) control for all electric and hydraulic functions
• Multi-step full stroke vises with split front vise and variable vise pressure control
• Spring loaded, zero clearance, coolant through, carbide faced saw guide with lead-in rollers
• Power driven, coolant flushed, blade cleaning wire brush
• Flushing hose and auxiliary coolant nozzles
• Hydraulic blade tension
• Automatic chip conveyor
• Blade breakage/stall motion detector shut off switch
• Band door interlocks
• Work light
• One set of 6-foot (2-meter) roller stands
• Set up tools and tool box
• Complimentary DoALL Cutting Fluids package
• One DoALL bi-metal saw blade
• Specifications
• Cutting Capacity Rectangle: 39.3" x 31.5"
• Band Saw Blade: 346.46 x 2.64 x 0.063"
• Band Drive: 15 hp
• Hydraulic Pump: 3 hp
• Hydraulic Tank Capacity: 22.5 gal
• Coolant Pump: 1/4 hp
• Coolant Tank Capacity: 58 gal
• Material Pass Line Height: 28.3"
• Machine Weight: 24251 lbs
• Dimensions W x L x H: 171.3 x 85 x 104.3"

Specifications

• Manufacturer: DoALL Sawing Products
• SKU: DC-800SA
• Shipping Method: Flatbed
• Weight: 24,300 lb
• Dimensions: 175 × 100 × 105 in
• Country of Origin: United States of America
