Dake Model SE1018 220V Single Phase 10” Round Capacity Standard Duty Variable Blade Speed Horizontal Bandsaw 983114

Dake Model SE1018 220V Single Phase 10” Round Capacity Standard Duty Variable Blade Speed Horizontal Bandsaw 983114 is a Dake Corporation product in the Band Saws collection.

Product Details

• Max Blade Speed: 65-260 fpm
• Bed Work Area: 23” x 11”
• Floor to Bed: 22½”
• Blade Size: 121.5” x 1”
• Description
• No tool takes more abuse than a horizontal bandsaw and nobody offers more dependable, trouble-free horizontal bandsaw than Dake. Their heavy-duty, double frame construction has been an industry standard since 1941. Since then, Dake’s horizontal bandsaws have provided problem-free performance and maintenance-free operation, year after year.
• Features
• High torque DC motor w/gear reducer eliminating belts and pulleys
• Variable speed dial – 65-250 fpm for on-the-fly-adjustment
• Digital Tachometer
• Hydraulic controlled, gravity head feed, for hands free cutting
• Hydraulically variable head feed control for regulation of head feeding rate. The machine automatically shuts off after the cut is complete
• Equipped with E-stop and restart protection
• Low voltage switches. Thermal overload protection, magnetic starter switch low voltage protection
• Vise miters up to 45°
• Vise has quick release for quick change over of material sizes
• Equipped with auxiliary 120V outlet
• Standard Equipment
• Recirculating coolant system
• Low voltage controls
• 6-8 TPI Standard Blade
• Specifications
• Capacity Solid Round 90°: 10” Solid Round 45°: 6” Solid Square 90°: 10” Solid Square 45°: 7” Solid Rectangle 90°: 5” x 18” Solid Rectangle 45°: 7” x 9”
• Solid Round 90°: 10”
• Solid Round 45°: 6”
• Solid Square 90°: 10”
• Solid Square 45°: 7”
• Solid Rectangle 90°: 5” x 18”
• Solid Rectangle 45°: 7” x 9”
• Blade Width: 1”
• Blade Length: 121.5”
• Blade Speeds: Variable Speed
• Horsepower: 2 HP DC motor
• Electrical Requirements: 220V Single Phase
• Machine Dims: 65” x 24” x 45”
• Approx Weight: 610 lbs

Specifications

• Manufacturer: Dake Corporation
• SKU: 983114
• Shipping Method: LTL Freight
• Weight: 670 lb
• Dimensions: 70 × 30 × 50 in
