U.S. Industrial Machinery 9″ X 49″ Variable Speed Milling Machine 2VH-3

U.S. Industrial Machinery 9″ X 49″ Variable Speed Milling Machine 2VH-3 is a U.S. Industrial Machinery product in the Milling Machines collection.

Product Details

• Spindle Travel: 5"
• Table Size: 9" x 49"
• Cross Travel (Y-axis): 12"
• Vertical Travel: 16"
• Description
• U.S. Industrial Machinery’s line of milling machines offers a ton of user flexibility to make precision cuts for beautiful finished work. At our Memphis, Tennessee facility we complete the assembly, calibrate, test, and perform cosmetic upgrades of all in-coming machinery to ensure sturdy, functional pieces of equipment that can be put to the test of the most demanding jobs. All equipment comes with a one-year part and labor warranty, and our technical support is always available to help you troubleshoot any user problems.
• Standard Equipment
• Power-feed on X-axis controlling longitudinal travel
• Backlash adjustment for leadscrews and gib adjustments for ways
• Hardened and ground and precisely scraped worktable, saddle and knee ways
• Stress relieved meehanite cast iron for long life and accuracy
• Digital readout with 0.0002 resolution
• Built in coolant tank base with coolant pump, pressure and return hose, nozzle and valve
• Installed and ready to use base chip pan to help prevent coolant overflow
• Conventional dovetail ways on X, Y and Z axes
• One shot lube system
• Hard-chromed ways
• Front and rear rubber way covers
• 24 volt halogen machine light
• Tool box with tools
• Dual voltage main motor wired 220V or 440V (3 phase) per customer’s preference
• Specifications
• Spindle Taper: R-8
• Quill Diameter: 3.375"
• Number of Spindle Speeds: Variable
• Spindle Speed Range (60HZ): 60-4,200 RPM
• Spindle Feed Range (Inches/Revolution) (3 Speeds): 0.0016", 0.003", 0.006"
• Head Tilt (Left to Right): 90°
• Head Tilt (Front to Back): 45°
• Maximum Distance Spindle to Table: 1.70"-17.70"
• Maximum Distance Spindle to Column: 17.30"
• Minimum Distance Spindle to Column: 8.25"
• Collet Capacity: 1/8"-5/8"
• Longitudinal Travel (X-axis) with Powerfeed: 30"
• Longitudinal Travel (X-axis) without Powerfeed: 34"
• Number of T-Slots: 3
• T-Slot Size: 5/8"
• T-Slot Centers: 2.5”
• Maximum Weight of Work Piece: 727 lbs
• Main Motor Horsepower: 3
• Weight: 2,820 lbs
• Floor Area (W x D x H): 66" x 63" x 86"
• Electrical: 220 or 440 volts, 3 phase
• Power Consumption (Amperage) (220/440 volt): 10/5
• Available Upgrades/Options
• Pneumatic drawbar for easy changing of tools
• Power feed for Y-axis (cross feed)
• Power feed for Z-axis (knee feed)
• Quick change collet set
• Clamping kit
• Precision parallel set in formed case
• 6” lock type vise
• R-8 collet set

Specifications

• Manufacturer: U.S. Industrial Machinery
• SKU: 2VH-3
• Shipping Method: Flatbed
• Weight: 2,600 lb
• Dimensions: 50 × 50 × 75 in
• Country of Origin: China
• Warranty: 1 Year (Parts)
