U.S. Industrial Machinery 63″ Radial Arm Drill Press USRD64-5

U.S. Industrial Machinery 63″ Radial Arm Drill Press USRD64-5 is a U.S. Industrial Machinery product in the Drill Presses collection.

Product Details

• Drilling Capacity: 2"
• Spindle Travel: 12.4"
• Spindle Feeds: .0016" to .126"
• Morse Taper 5 Spindle
• Standard Equipment
• Two side box work table, t-slotted
• T-slotted base
• Flood Coolant System
• Power Arm Elevation
• Power Arm Clamp
• High Precision, Low Noise Ground Gears
• 12" + drilling depth
• Specifications
• Min and Max Spindle to Column: 13.8" to 63"
• Diameter of Column: 13.8"
• Spindle Type: Morse Taper 5 Spindle
• Spindle Speeds: 25 to 2500 RPM (16 speed gear driven)
• Spindle Feeds Per Revolution: .0016" to .126" (16 feeds)
• Min and Max Distance Spindle to base: 12.6" to 48"
• Box Table Dimensions: 24.8" x 19.7" x 19.7"
• Base Dimensions: 94.5" x 39.3" x 7.9"
• Overall Dimensions: 98.4" x 41.7" x 104"
• Main Spindle Drive: 5.4 HP (208-240 or 440-480v, 3 ph)
• Gross/ Net Weight: 8580 lbs / 7700 lbs

Specifications

• Manufacturer: U.S. Industrial Machinery
• SKU: USRD64-5
• Shipping Method: Flatbed
• Weight: 8,600 lb
• Dimensions: 99 × 42 × 104 in
• Country of Origin: China
• Warranty: 1 Year (Parts)
