Palmgren 1.5HP 230V Three Phase 20” Gear Head Drill Press with Foot Reversing Switch 9680243

Palmgren 1.5HP 230V Three Phase 20” Gear Head Drill Press with Foot Reversing Switch 9680243 is a Palmgren product in the Drill Presses collection.

Product Details

• Capacity Steel: 1"
• Capacity Cast Iron: 1-1/8"
• Power Feed: No
• Number Of Speeds: 8
• Description
• This versatile all gear drive drill press is the right choice for precision drilling applications and continuous industrial use. The gear drive transmission delivers full power at any speed, driving the cutting tools at nearly 100% of the available motor horsepower. Helical ground gears ensure positive, quite operation and make speed changes fast and easy. The wide speed range makes this the ideal drill for drilling large to small diameter holes fast and easy.
• Features
• Inch/Metric depth stop
• 2 speed manual forward & reverse switch on 3 PH models
• Foot reversing switch
• Head & table rotates 360 degrees around the column
• Machined & t-slotted table
• Quick release drill ejector
• Chuck guard
• No-volt release prevents spindle start up when power returns after shutdown
• 4" Palmgren drill press vise
• Drill chuck & arbor
• Made in Sweden
• Specifications
• Swing: 20"
• Spindle Taper: MT3
• Motor: 1-1/2 HP, 230V, 3PH
• Spindle Speed: 130-3480 RPM
• Spindle Travel: 5-1/8"
• Base Size: 15-3/4" x 20"
• Table Work Surface: 20" x 15-3/4"
• Number Of T-Slots: 3
• Table Slot Size: 1"
• Column Diameter: 4"
• Spindle To Table: 32-3/4"
• Overall Dimensions: 15-3/4" x 20" x 82"
• Weight: 429 lbs.

Specifications

• Manufacturer: Palmgren
• SKU: 9680243
• UPC: 726896802435
• Shipping Method: LTL Freight
• Weight: 529 lb
• Dimensions: 21 × 25 × 87 in
• Country of Origin: Sweden
• Warranty: 3 Years (Parts)
