North America Phase Converter SB-60

North America Phase Converter SB-60 is a North America Phase Converters product in the Phase Converters collection.

Product Details

• Horse Power (HP) 60
• Generator Type ODP
• High Speed/High Efficiency Design
• Output Power Failure Protection
• Description
• Smart-Boost™ Digital Controller
• Motor Starter with Start/Stop Switch
• High Current Protective Coils
• Power "ON" Indicator Light
• Easy Installation
• Large Wiring Compartment
• Power Factor Corrected
• Made In the USA
• Features
• Custom Made Phase Converter Generators
• Low Impedance/Delta Design
• Custom Copper Windings and Rotor
• Corrosion Resistant Paint
• Made by Baldor Electric USA
• Vacuum Pressure Impregnation for all Windings
• Shielded Windings
• Specifications
• Kilo-watt (kW) 44.7
• Frequency (Hz) 60
• Enclosure Type NEMA 1 (Indoor)
• Generator Frame 364
• Enclosure (H X W X D) 24" X 18" X 8"
• Idler (Approx.) Length X Dia. 22.5" X 15.25"
• Approx. Total Shipping Weight 455 lbs
• Smart-Boost™ Model and Sizing Chart
• Rotary Converter HP: Motor Loads (Horsepower) | CNC, Resistive & Inductive Loads | Smart-Boost™ Rotary Converter Model
• Easy: Med | Hard | Very Hard | Total Amps | Total kVA | Total kW | Spindle HP
• 3: 3 | 3 | 2 | 1.5 | N/A | N/A | N/A | N/A | SB-3
• 5: 5 | 5 | 3 | 2 | N/A | N/A | N/A | N/A | SB-5
• 7.5: 7.5 | 7.5 | 5 | 3 | 12 | 5 | 2.5 | 3.5 | SB-7
• 10: 10 | 10 | 6 | 5 | 16 | 6 | 3.7 | 5 | SB-10
• 15: 15 | 15 | 7.5 | 7.5 | 25 | 8 | 5.6 | 7.5 | SB-15
• 20: 20 | 20 | 12 | 10 | 32 | 10 | 7.7 | 10 | SB-20
• 25: 25 | 25 | 15 | 12 | 40 | 12 | 9.5 | 12 | SB-25
• 30: 30 | 30 | 20 | 15 | 49 | 21 | 11.8 | 15 | SB-30
• 40: 40 | 40 | 25 | 20 | 61 | 25 | 15.5 | 20 | SB-40
• 50: 50 | 50 | 30 | 25 | 76 | 30 | 21.5 | 25 | SB-50
• 60: 60 | 60 | 40 | 30 | 84 | 34 | 26.5 | 30 | SB-60

Specifications

• Manufacturer: North America Phase Converters
• SKU: SB-60
• Shipping Method: LTL Freight
• Weight: 455 lb
