Mittler Bros English Wheel Sheet Metal Shaper Station 3200

Mittler Bros English Wheel Sheet Metal Shaper Station 3200 is a Mittler Bros product in the Metal Forming & Shaping collection.

Product Details

• Throat Depth 32" to center of wheel
• Working Height 47" Width 52" Depth 55"
• Upper Wheel 2" wide x 4-1/2" Dia.
• Max Capacity: 16 GA Mild Steel, 10 GA Soft Aluminum
• Features
• Hammering / Blocking to pre-form the custom aluminum or steel parts
• Wheeling and raising metal panels
• Shrinking or stretching
• Planishing; Perfect for motorcycle tanks, hood scoops, fender flares, door skins, etc.
• Includes:
• Stand
• Shrinker / Stretcher Body with Jaws
• 1 Forming Head (MFH09 Classic Bowl)
• 12” Shot Bag
• 6 Lower Flat Top Anvil Wheels
• Unique Upper Wheel “CAM” Release Foot Operated Shrinker / Stretcher
• Specifications
• Max. Anvil Opening 1" Weight 475 lbs.
• Rolls Case Hardened
• 6 Flat Top Anvil Wheels (2-1/2" Dia x 2" Wide) Included: 2900-A0 = Flat 2900-A1 = 12" Radius with 3/4" Flat 2900-A2 = 8-1/2" Radius with 1/2" Flat 2900-A3 = 5" Radius with 3/8" Flat 2900-A4 = 3-1/4" Radius with 1/4" Flat 2900-A5 = 2-3/8" Radius with 1/8" Flat
• 2900-A0 = Flat
• 2900-A1 = 12" Radius with 3/4" Flat
• 2900-A2 = 8-1/2" Radius with 1/2" Flat
• 2900-A3 = 5" Radius with 3/8" Flat
• 2900-A4 = 3-1/4" Radius with 1/4" Flat
• 2900-A5 = 2-3/8" Radius with 1/8" Flat
• CNC Machined Heat-Treated Steel
• Max Capacity: 16 GA (.059") Mild Steel 10 GA (.100") Soft Aluminum
• 16 GA (.059") Mild Steel
• 10 GA (.100") Soft Aluminum

Specifications

• Manufacturer: Mittler Bros
• SKU: 3200
• Shipping Method: LTL Freight
• Weight: 665 lb
• Dimensions: 48 × 48 × 65 in
• Country of Origin: United States of America
• Warranty: 1 Year (Parts)
