Heck High Production Power Feed Beveling Machine PRO-12G

Heck High Production Power Feed Beveling Machine PRO-12G is a Heck Industries Inc product in the Beveling Machines collection.

Product Details

• Fast and Accurate Beveling
• Self-Propelled
• Direct Drive Gear Boxes – No Inefficient Belts
• Variable Angle by single hand wheel
• Description
• PRO-12G Power Feed Beveler The PRO12G adds the ability to change the angle of bevel simply by adjusting the single hand wheel from 20 to 45°. Great for applications where multiple angles are needed as the adjustment of this machine is very fast. No more replacement of tooling and rollers.
• This machine performs 6 feet/min. at a maximum bevel depth of .625 inches. It can handle material up to 1 1/4” thickness. A spring loaded trolley is included.
• Features
• Simple, Quiet Operation
• Specifications
• Maximum Bevel Depth: .625″
• Maximum Material Thickness: 1.25″
• Minimum Material Thickness: .250″
• Bevel Speed: 6fpm
• Bevel-Angle: 20-45°
• Motor: 3hp
• Weight: 242 lbs

Specifications

• Manufacturer: Heck Industries Inc
• SKU: PRO-12G
• Shipping Method: LTL Freight
• Weight: 242 lb
